90143-0014
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSNG 14POS .100 DL CRIMP
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.951151
≥1 USD $0.951151
≥10 USD $0.897306
≥100 USD $0.846523
≥500 USD $0.798607
≥1000 USD $0.753402
Inventory: 971
Minimum: 1
-
+
Technical Details
Technical
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Body/Shell Style PLUG
Dielectric Withstanding Voltage 1000VDC V
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Rated Current (Signal) 3A
Body Depth 0.6 inch
UL Flammability Code 94V-1
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 14
Row Spacing - Mating 2.54 mm
Body Length or Diameter 0.7 inch
Reliability COMMERCIAL
Current Rating 3A
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature C-GRID III, POLARIZED
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2011
Packaging Bulk
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material PPO
Mount Cable, Free Hanging
Supply Chain
Factory Lead Time 9 Weeks
