70107-0036
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HSNG MALE 2POS .100 PNL MT
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.433713
≥1 USD $1.433713
≥10 USD $1.352565
≥100 USD $1.275996
≥500 USD $1.20377
≥1000 USD $1.135642
Inventory: 3175
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Panel
Housing Material Polyester
Technical
Published 2010
Pbfree Code yes
Part Status Active
Termination Crimp
Connector Type Male Pin, Plug
Max Operating Temperature 120°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Straight
Depth 24.26mm
Reference Standard UL, CSA
Reliability COMMERCIAL
Number of Contacts 2
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 30mOhm
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Wire Size (Min) 36 AWG
Glow Wire Compliant Non-compliant
Dimensions
Length 16.51mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
