51005-0500

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description CONN RCPT 5POS 2MM WIRE TO WIRE
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.431459
≥1 USD $0.431459
≥10 USD $0.407035
≥100 USD $0.383995
≥500 USD $0.362254
≥1000 USD $0.341757
Inventory: 4843
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 2.7mm
Length 12.6mm

Technical

Glow Wire Compliant Non-compliant
Wire Size (Min) 28 AWG
Contact Pattern RECTANGULAR
Wire/Cable Gauge 24 AWG
Polarization Key GUIDE SLOT(S)
Insulation Resistance 1GOhm
Contact Resistance 20MOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 2A
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 5
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 2A
Depth 9.2mm
Orientation Straight
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Receptacle
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Packaging Bulk

Physical

Housing Material Polyester
Mount Cable, Free Hanging
