50-37-5093
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING 9POS 2.5MM SHROUD
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.121924
≥1 USD $0.121924
≥10 USD $0.115025
≥100 USD $0.108513
≥500 USD $0.102376
≥1000 USD $0.096579
Inventory: 3799
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Cable, Free Hanging
Housing Material Polyamide
Body Material Nylon, Polyamide
Technical
Packaging Bulk
Published 2008
Pbfree Code yes
Part Status Active
Termination Crimp
Connector Type Receptacle, Socket
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Receptacle
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.5mm
Orientation Straight
Depth 8mm
Reference Standard UL, CSA
Reliability COMMERCIAL
Number of Contacts 9
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
Operating Supply Voltage 250V
Rated Current (Signal) 3A
Contact Style RND PIN-SKT
Contact Resistance 20mOhm
Polarization Key POLARIZED HOUSING
Durability 30 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 8.0064 N
Halogen Free Low Halogen
Wire Size (Min) 28 AWG
Wire Size (Max) 22 AWG
Glow Wire Compliant Non-compliant
Insulation Diameter-Min 0.045 inch
Dimensions
Length 23.3mm
Width 3.9mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
