43025-0800
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
MOLEX 43025-0800Connector Housing, Dual Row, Micro-Fit 3.0 Series, 8 Ways, 3 mm
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1387
≥1 USD $0.1387
≥10 USD $0.114
≥100 USD $0.1102
≥500 USD $0.1064
≥1000 USD $0.10355
Inventory: 4278
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 11.56mm
Length 12.85mm
Technical
Voltage - Working 250V
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Max Voltage Rating (DC) 600.6kV
Max Voltage Rating (AC) 600V
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender Female
Number of Contacts 8
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Depth 14mm
Orientation Straight
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature MICRO-FIT 3.0, POLARIZED
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Power, Rectangular
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2010
Packaging Bulk
Physical
Housing Material Polyester
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Bronze, Tin
Supply Chain
Factory Lead Time 14 Weeks
