43025-0600

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description MOLEX - 43025-0600 - Connector Housing, Dual Row, Micro-Fit 3.0 43025 Series, Receptacle, 6 Ways, 3 mm
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.20869
≥1 USD $0.20869
≥10 USD $0.19687
≥100 USD $0.18573
≥500 USD $0.17522
≥1000 USD $0.1653
≥3000 USD $0.15594
Inventory: 15102
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 11.56mm
Length 9.85mm

Technical

Voltage - Working 250V
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Withdrawl Force-Min 3.5584 N
Max Voltage Rating (DC) 600.6kV
Number of Poles 6
Max Voltage Rating (AC) 600V
Number of Circuits 6
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Contact Gender Female
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Depth 14mm
Orientation Straight
Total Number of Contacts 6
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Additional Feature MICRO-FIT 3.0, POLARIZED
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Power, Rectangular
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2006
Packaging Bulk

Physical

Material Polyester
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Bronze, Tin

Supply Chain

Factory Lead Time 9 Weeks
