39-01-4052
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 5POS VERT PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.256132
≥1 USD $0.256132
≥10 USD $0.241636
≥100 USD $0.227957
≥500 USD $0.215056
≥1000 USD $0.202882
Inventory: 3167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Panel, Snap in
Shell Material POLYAMIDE66
Housing Material Nylon
Technical
Packaging Bulk
Published 2007
Pbfree Code yes
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Male Pin, Pin, Plug
Number of Positions 5
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Gender Male
Additional Feature PANEL MOUNTABLE
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 600V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 4.2mm
Total Number of Contacts 5
Orientation Straight
Depth 23.9mm
Current Rating 13A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-2
Empty Shell NO
Contact Style SQ PIN-SKT
Dielectric Withstanding Voltage 2200VAC V
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 20 AWG
Durability 30 Cycles
Max Voltage Rating (DC) 600.6kV
Insertion Force-Max 6.672 N
Halogen Free Low Halogen
Number of Lines 1
Glow Wire Compliant Non-compliant
Dimensions
Diameter 4.2mm
Length 22.2mm
Width 7.4mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
