39-01-2181
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 18POS PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $5.26
Unit Price: USD $5.2592
≥1 USD $5.2592
≥10 USD $4.3149
≥100 USD $4.18
≥500 USD $4.0451
≥1000 USD $3.91115
Inventory: 3507
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 11.6mm
Length 44.4mm
Technical
Insulation Diameter-Min 0.035 inch
Voltage - Working 250V
Wire Size (Max) 16 AWG
Withdrawl Force-Min 3.1136 N
Max Voltage Rating (DC) 600.6kV
Number of Poles 18
Durability 30 Cycles
Polarization Key CENTER
Max Voltage Rating (AC) 600V
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Empty Shell YES
Body Breadth 0.378 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Lead Pitch 4.2mm
Row Spacing - Mating 4.191 mm
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL, CSA
Current Rating 13A
Depth 23.9mm
Orientation Straight
Total Number of Contacts 18
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.30
Gender Male
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin, Pin, Plug, Power, Rectangular
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Published 2009
Packaging Bulk
Physical
Housing Material Nylon
Mount Panel, Snap in
Supply Chain
Factory Lead Time 6 Weeks
