39-01-2121
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 12POS PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3919
≥1 USD $0.3919
≥10 USD $0.369718
≥100 USD $0.348787
≥500 USD $0.329045
≥1000 USD $0.31042
Inventory: 2767
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 12mm
Length 31.8mm
Technical
Insulation Diameter-Min 0.035 inch
Glow Wire Compliant Non-compliant
Wire Size (Max) 16 AWG
Halogen Free Low Halogen
Withdrawl Force-Min 3.1136 N
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 600.6kV
Durability 30 Cycles
Polarization Key CENTER
Max Voltage Rating (AC) 600V
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Empty Shell YES
Contact Gender Male
Body Breadth 0.378 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 12
Row Spacing - Mating 4.191 mm
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL, CSA
Current Rating 13A
Depth 23.9mm
Orientation Straight
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.30
Voltage - Rated 600V
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin, Pin, Plug
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2010
Packaging Bulk
Physical
Housing Material Nylon
Number of Pins 10
Mount Panel, Snap in
Supply Chain
Factory Lead Time 8 Weeks
