39-01-2105
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
MOLEX 39-01-2105Connector Housing, Pull Tabs, UL 94V-0, Mini-Fit Jr. Series, Receptacle, 10 Ways, 4.2 mm
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.262549
≥1 USD $0.262549
≥10 USD $0.247695
≥100 USD $0.233667
≥500 USD $0.220436
≥1000 USD $0.207965
Inventory: 1235
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 15.1mm
Length 22.2mm
Height 15.1mm
Technical
Glow Wire Compliant Non-compliant
Current Rating (Max) 9A
Halogen Free Low Halogen
Max Voltage Rating (DC) 600.6kV
Dielectric Withstanding Voltage 1500VAC V
Max Voltage Rating (AC) 600V
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Empty Shell NO
Housing Color Beige
UL Flammability Code 94V-0
Contact Gender Female
Body Breadth 0.46 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 10
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Voltage - Rated AC 600V
Reference Standard UL
Number of Conductors ONE
Current Rating 13A
Depth 19.6mm
Orientation Straight
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 600V
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Natural, White
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Socket
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2008
Packaging Bulk
Physical
Housing Material Polyamide
Material Nylon
Number of Pins 8
Mount Cable
Supply Chain
Factory Lead Time 8 Weeks
