33482-1601
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 16POS DUAL BLACK
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.819289
≥1 USD $0.819289
≥10 USD $0.772914
≥100 USD $0.729164
≥500 USD $0.687888
≥1000 USD $0.648952
Inventory: 1349
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Contact Design PREASSEM CONN
Insulator Color BLACK
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.138 inch
Contact Style BLADE PIN-SKT
Rated Current (Signal) 22A
Empty Shell NO
Operating Temperature (Min) -40°C
Contact Gender MALE
Body Breadth 0.897 inch
Operating Temperature (Max) 125°C
Body Length or Diameter 1.435 inch
Reliability COMMERCIAL
Reference Standard UL
Reach Compliance Code compliant
Total Number of Contacts 16
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature POLARIZATION AVAILABLE
Number of Rows 2
Connector Type COMBINATION LINE CONNECTOR
Part Status Active
Pbfree Code icon-pbfree yes
Published 2010
Physical
Mounting Option 1 LOCKING
Shell Material GLASS FILLED POLYAMIDE/SYNDIOTACTIC POLYSTYRENE
Insulation Material GLASS FILLED NYLON
Mounting Type CABLE
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 8 Weeks
