29-11-0042
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings 2.5 SPOX PLUG HSG 4
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.102836
≥1 USD $0.102836
≥10 USD $0.097017
≥100 USD $0.09153
≥500 USD $0.086348
≥1000 USD $0.081458
Inventory: 9484
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 18.5mm
Length 13.6mm
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 250.25kV
Durability 30 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 4
Reliability COMMERCIAL
Reference Standard UL,CSA,TUV
Depth 7.9mm
Orientation Straight
Pitch 2.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2009
Packaging Bulk
Physical
Housing Material Nylon
Mount Panel
Supply Chain
Factory Lead Time 9 Weeks
