22-55-2522
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings Obsolete
PDF
/
Inventory: 6042
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 15.2mm
Length 66mm
Height 5.05mm
Technical
Contact Pattern RECTANGULAR
Polarization Key CENTER
Body Depth 0.6 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender FEMALE
Body Breadth 0.319 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 52
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Reach Compliance Code unknown
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Published 2008
Packaging Bulk
Physical
Housing Material Polyester
Mount Free Hanging
Contact Material NOT SPECIFIED
