22-01-3037
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings HSG 3P W/RAMP/RIBS
PDF
/
Buying Options
Total Price: USD $0.05
Unit Price: USD $0.05137
≥1 USD $0.05137
≥500 USD $0.037772
≥1000 USD $0.031481
≥2000 USD $0.028876
≥5000 USD $0.02699
≥10000 USD $0.025098
≥15000 USD $0.024282
≥50000 USD $0.023879
Inventory: 1078
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 4.82mm
Length 8.18mm
Height 4.82mm
Technical
Glow Wire Compliant Non-compliant
Wire Size (Max) 22 AWG
Wire Size (Min) 28 AWG
Current Rating (Max) 4A
Halogen Free Low Halogen
Withdrawl Force-Min .556 N
Contact Pattern RECTANGULAR
Durability 25 Cycles
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Contact Style SQ PIN-SKT
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 3
Lead Pitch 2.54mm
Approval Agency CSA, UL
Reliability COMMERCIAL
Reference Standard UL, CSA
Depth 12.7mm
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature POLARIZED
Voltage - Rated 250V
Gender Receptacle
Number of Rows 1
Color White
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Connector Type Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2001
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable
Contact Material Brass, Bronze
Supply Chain
Factory Lead Time 6 Weeks
