19-09-1159
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPTACLE 15POS .093
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.953599
≥1 USD $0.953599
≥10 USD $0.899624
≥100 USD $0.848693
≥500 USD $0.800662
≥1000 USD $0.755341
Inventory: 1605
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 34.4mm
Height 830μm
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Contact Style RND PIN-SKT
Empty Shell YES
UL Flammability Code 94V-2
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 15
Row Spacing - Mating 6.7056 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 9A
Depth 29.9mm
Orientation Straight
Pitch 6.7mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
Additional Feature POLARIZED
Gender Receptacle
Number of Rows 3
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male or Female, Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2002
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mount Cable, Free Hanging
Supply Chain
Factory Lead Time 8 Weeks
