19-09-1156

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description CONN RECEPTACLE 15POS .093
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.580461
≥1 USD $0.580461
≥10 USD $0.54761
≥100 USD $0.516609
≥500 USD $0.487369
≥1000 USD $0.45978
Inventory: 3288
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-2
RoHS Status RoHS Compliant

Dimensions

Height 830μm

Technical

Glow Wire Compliant Non-compliant
Contact Rating (Current) 9A
Halogen Free Low Halogen
Contact Style RND PIN-SKT
Body Depth 1.18 inch
Empty Shell YES
UL Flammability Code 94V-0
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Row Spacing - Mating 6.7056 mm
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 7.5A
Orientation Straight
Total Number of Contacts 15
Pitch 6.7mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
Additional Feature POLARIZED
Voltage - Rated 600V
Gender Female
Number of Rows 3
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 15
Connector Type Male or Female, Plug, Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2006
Packaging Bulk

Physical

Body Material Nylon, Polyamide
Housing Material Nylon
Mount Cable, Free Hanging
Contact Material NOT SPECIFIED

Supply Chain

Factory Lead Time 9 Weeks
