09-50-7061

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description CONN HOUSING 6POS .156 W/O RAMP
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.304067
≥1 USD $0.304067
≥10 USD $0.286861
≥100 USD $0.270621
≥500 USD $0.255298
≥1000 USD $0.240845
Inventory: 1371
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Width 15.88mm
Length 23.67mm
Height 15.9mm

Technical

Contact Pattern RECTANGULAR
Max Voltage Rating (AC) 250V
Body/Shell Style PLUG
Contact Style BELLOWED TYPE
UL Flammability Code 94V-2
Body Breadth 0.25 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 6
Lead Pitch 3.96mm
Approval Agency CSA, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Depth 6.4mm
Orientation Straight
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Receptacle
Number of Rows 1
Color Natural
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Published 2011
Packaging Bulk

Physical

Body Material Nylon, Polyamide
Housing Material Nylon
Mount Cable, Free Hanging
Contact Material Brass, Bronze

Supply Chain

Factory Lead Time 8 Weeks
