09-50-3161
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT 16POS .156 W/RAMP
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.050785
≥1 USD $1.050785
≥10 USD $0.99131
≥100 USD $0.935206
≥500 USD $0.882265
≥1000 USD $0.832322
Inventory: 1355
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Cable, Free Hanging
Housing Material Nylon
Body Material Nylon, Polyamide
Technical
Published 2012
Pbfree Code yes
Termination Crimp
ECCN Code EAR99
Connector Type Receptacle, Socket
Number of Positions 16
Max Operating Temperature 75°C
Min Operating Temperature 0°C
Color Natural
Number of Rows 1
Gender Receptacle
HTS Code 8536.69.40.40
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 3.96mm
Total Number of Contacts 16
Orientation Straight
Depth 15.88mm
Reference Standard UL
Reliability COMMERCIAL
Approval Agency CSA, UL
Lead Pitch 3.96mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.25 inch
Contact Gender Female
UL Flammability Code 94V-2
Contact Style BELLOWED TYPE
Body/Shell Style PLUG
Max Voltage Rating (AC) 250V
Contact Pattern RECTANGULAR
Dimensions
Length 63.3mm
Width 6.4mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
