09-50-3091
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING 9POS .156 W/RAMP
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.489909
≥1 USD $0.489909
≥10 USD $0.462179
≥100 USD $0.436024
≥500 USD $0.411335
≥1000 USD $0.388051
Inventory: 6433
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 6.4mm
Length 35.56mm
Height 6.4mm
Technical
Current Rating (Max) 7A
Contact Pattern RECTANGULAR
Max Voltage Rating (AC) 250V
Body/Shell Style PLUG
Contact Style BELLOWED TYPE
Contact Gender Female
Body Breadth 0.25 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 9
Approval Agency CSA, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Depth 15.88mm
Orientation Straight
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Gender Receptacle
Number of Rows 1
Color Natural
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Connector Type Receptacle, Socket
Termination Crimp
Pbfree Code yes
Published 2010
Physical
Housing Material Nylon
Mount Cable, Free Hanging
Contact Material Brass, Bronze
Supply Chain
Factory Lead Time 8 Weeks
