03-12-2035

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Headers & Wire Housings 3 CKT HOUSING .125 HCS-125
PDF
/
Inventory: 5816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Panel, Snap in
Shell Material POLYAMIDE66
Housing Material Nylon
Weight 4.212994g

Technical

Packaging Bulk
Published 2011
Pbfree Code yes
Termination Crimp
ECCN Code EAR99
Connector Type Male or Female, Plug, Socket
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Natural
Number of Rows 1
Gender Male
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 8.38mm
Orientation Straight
Current Rating 20A
Reference Standard UL, CSA
Reliability COMMERCIAL
Lead Pitch 8.38mm
Number of Contacts 3
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.6 inch
UL Flammability Code 94V-2
Empty Shell NO
Operating Supply Voltage 600V
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Contact Design STRIP OR LOOSE

Dimensions

Length 25.9mm

Compliance

Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free
