03-06-2241
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 24POS .062 PANEL MOUNT
PDF
/
Inventory: 2384
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 18.8mm
Length 26.1mm
Technical
Glow Wire Compliant Non-compliant
Contact Style RND PIN-SKT
Operating Supply Voltage 250V
Empty Shell YES
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 24
Row Spacing - Mating 3.683 mm
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 4A
Depth 19.1mm
Orientation Straight
Pitch 3.68mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Detent
Additional Feature COMPATIBLE CONTACTS: 02-06-1101; 02-06-1131; 02-06-2101, FRICTION LOCK, POLARIZED
Number of Rows 4
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male or Female, Plug, Socket
Termination Crimp
Pbfree Code yes
Published 2000
Packaging Bulk
Physical
Housing Material Nylon
Mount Cable, Panel, Snap in
Supply Chain
Factory Lead Time 5 Weeks
