03-06-2151
RoHS
/
Package 062
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 15POS .062 PANEL MOUNT
PDF
/
Inventory: 8275
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 15mm
Length 22.1mm
Height 25.4mm
Technical
Glow Wire Compliant Non-compliant
Contact Style RND PIN-SKT
Operating Supply Voltage 250V
Empty Shell YES
UL Flammability Code 94V-2
Contact Gender Male
Body Breadth 0.59 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 15
Row Spacing - Mating 3.683 mm
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 5A
Depth 19mm
Orientation Straight
Pitch 3.68mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Detent
Number of Rows 3
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male or Female, Plug, Socket
Termination Crimp
Pbfree Code yes
Published 2007
Packaging Bulk
Physical
Weight 4.535924g
Housing Material Nylon
Package / Case 062
Mount Panel, Snap in
Supply Chain
Factory Lead Time 4 Weeks
