03-06-1042

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description PLUG & SOCKET HOUSING, RECEPTACLE, NYLON
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.343684
≥1 USD $0.343684
≥10 USD $0.32424
≥100 USD $0.305883
≥500 USD $0.28856
≥1000 USD $0.272228
Inventory: 1112
Minimum: 1
-
+

Technical Details

Dimensions

Height 5mm
Length 16mm
Width 5mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Lead Free

Technical

Glow Wire Compliant Non-compliant
Current Rating (Max) 5A
Halogen Free Halogen Free
Contact Style RND PIN-SKT
Operating Supply Voltage 250V
Empty Shell NO
Contact Gender Female
Body Breadth 0.2 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Approval Agency CSA, TUV, UL
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Depth 19.8mm
Orientation Straight
Total Number of Contacts 4
Pitch 3.68mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Receptacle
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Socket
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Published 2006

Physical

Weight 4.535924g
Housing Material Nylon
Shell Material POLYAMIDE
Mount Cable, Panel

Supply Chain

Factory Lead Time 8 Weeks
