XARR-07V
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
JST (JAPAN SOLDERLESS TERMINALS) XARR-07V Wire-To-Board Connector, Lock, Receptacle, 7 Contacts, 2.5 mm
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.2376
≥1 USD $0.2376
≥10 USD $0.20416
≥100 USD $0.136066
≥500 USD $0.113388
≥1000 USD $0.097187
≥3000 USD $0.09071
Inventory: 76
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Panel
Mounting Type Panel Mount, Snap-In
Housing Material Nylon
Weight 18.143695g
Technical
Packaging Bulk
Published 2004
Series XA
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 7
Color Natural
Number of Rows 1
Voltage - Rated 250V
HTS Code 8536.69.40.40
Fastening Type Latch Lock
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option WITH CABLE ASSEMBLY
Pitch 0.098 2.50mm
Total Number of Contacts 7
Orientation Straight
Current Rating 3A
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Note Contacts Not Included
Contact Termination Crimp
Dimensions
Height 23.876mm
Length 11.938mm
Width 23.876mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
