MX23A26SF1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN SOCKET HOUSING 26POS MX23A
PDF
/
Buying Options
Total Price: USD $16.59
Unit Price: USD $16.58985
≥1 USD $16.58985
≥10 USD $13.61255
≥100 USD $13.18695
≥500 USD $12.76135
≥1000 USD $12.3367
Inventory: 3654
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material PBT, Polybutylene
Technical
Packaging Bulk
Published 2003
Series MX23A
Feature Waterproof
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 26
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Fastening Type Latch Lock
Contact Type Female Socket
Pitch 0.098 2.50mm
Current Rating 3A
Insulation Resistance 100MOhm
Row Spacing 0.173 (4.40mm)
Note Contacts Not Included
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 22 AWG
Contact Termination Crimp
Outside Diameter 2.2 mm
Dimensions
Length 46.6mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
