DF62B-4S-2.2C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
DF62 RoHS Compliant COMMERCIAL UL Socket Connector Housing 30Cycles 30mOhm 105C 3A
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.395528
≥1 USD $0.395528
≥10 USD $0.373139
≥100 USD $0.35202
≥500 USD $0.332093
≥1000 USD $0.313296
Inventory: 3565
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Free Hanging, Panel
Mounting Type Free Hanging (In-Line)
Housing Material PBT
Technical
Packaging Bulk
Series DF62
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Socket
Number of Positions 4
Color White
Number of Rows 2
Gender Receptacle
Fastening Type Latch Lock
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.087 2.20mm
Total Number of Contacts 4
Orientation Straight
Depth 7.08mm
Reach Compliance Code unknown
Reference Standard UL
Reliability COMMERCIAL
Operating Temperature (Max) 105°C
Operating Temperature (Min) -35°C
Rated Current (Signal) 3A
Contact Resistance 30mOhm
Insulation Resistance 1000000000Ohm
Row Spacing 0.079 (2.00mm)
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 650VAC V
Durability 30 Cycles
Contact Termination Crimp
Dimensions
Length 9.55mm
Width 4.9mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
