DF22-2EP-7.92C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Conn Wire to Board PL 2 POS 7.92mm Crimp ST Cable Mount
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.377094
≥1 USD $0.377094
≥10 USD $0.355747
≥100 USD $0.335613
≥500 USD $0.316615
≥1000 USD $0.298694
Inventory: 3150
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material COPPER ALLOY
Contact Plating Copper, Lead, Tin
Mount Panel
Mounting Type Panel Mount
Housing Material Polyamide
Technical
Packaging Bulk
Series EnerBee? DF22
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug
Number of Positions 2
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Natural
Number of Rows 1
Voltage - Rated 1kV
Fastening Type Latch Holder
Contact Finish - Mating TIN COPPER
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.312 7.92mm
Total Number of Contacts 2
Orientation Straight
Depth 35.95mm
Reach Compliance Code unknown
Current Rating 25A
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
UL Flammability Code 94V-0
Housing Color Beige
Contact Resistance 5mOhm
Insulation Resistance 1GOhm
Note Contacts Not Included
Max Voltage Rating (AC) 600V
Max Current Rating 30A
Wire Gauge (Max) 10 AWG
Wire Gauge (Min) 16 AWG
Contact Termination Crimp
Dimensions
Length 23.22mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
