DF1E-2S-2.5C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT HOUSING 2POS 2.5MM
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.10735
≥1 USD $0.10735
≥10 USD $0.08835
≥100 USD $0.0855
≥500 USD $0.08265
≥1000 USD $0.0798
Inventory: 3351
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 8mm
Height 7.55mm
Technical
Contact Termination Crimp
Durability 30 Cycles
Dielectric Withstanding Voltage 650VAC V
Polarization Key POLARIZED HOUSING
Max Current Rating 3A
Max Voltage Rating (AC) 250V
Note Contacts Not Included
Contact Resistance 30mOhm
Rated Current (Signal) 3A
UL Flammability Code 94V-0
Contact Gender Female
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Current Rating 3A
Depth 11.8mm
Orientation Straight
Total Number of Contacts 2
Pitch 0.098 2.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Latch Lock
Voltage - Rated 250V
Number of Rows 1
Color White
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Number of Positions 2
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series DF1E
Packaging Bulk
Physical
Housing Material Polyamide
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 10 Weeks
