RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Rectangular Connector Housing
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
Inventory: 1009
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Length 18mm
Height 6mm

Technical

Wire Size (Max) 24 AWG
Wire Size (Min) 28 AWG
Contact Termination Crimp
Insertion Force-Max 4.3924 N
Durability 30 Cycles
Polarization Key HOUSING SIDE
Note Contacts Not Included
Body Depth 0.382 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -30°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL
Current Rating 3A
Reach Compliance Code unknown
Total Number of Contacts 6
Pitch 0.098 2.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Brown
Number of Positions 6
Connector Type Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series DF1
Packaging Bulk

Physical

Housing Material Polyamide
Mounting Type Free Hanging (In-Line)
Contact Material PHOSPHOR COPPER

Supply Chain

Factory Lead Time 10 Weeks
