M80-4592698
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Datamate Trio-Tek ROHS3Compliant COMMERCIAL UL Receptacle Connector Housing 400Cycles 22AWG -55C 3A
PDF
/
Inventory: 2747
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Contact Termination Crimp
Durability 400 Cycles
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 22 AWG
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Note Contacts Not Included
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Rated Current (Signal) 3A
Body Depth 0.437 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender Male
Lead Pitch 2mm
Body Length or Diameter 1.417 inch
Reliability COMMERCIAL
Reference Standard UL
Current Rating 3A
Total Number of Contacts 26
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Fastening Type Screw Lock
HTS Code 8536.69.40.40
Additional Feature POLARIZED
Voltage - Rated 120V
Number of Rows 2
Color Black
Number of Positions 26
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
Series Datamate Trio-Tek
Published 2009
Packaging Bulk
Physical
Housing Material Polyamide
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 13 Weeks
