M80-4562698
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
POLARIZED Rectangular Connector Housing
PDF
/
Inventory: 9877
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material NOT SPECIFIED
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYAMIDE
Technical
Packaging Bulk
Series Datamate Trio-Tek
Feature Jackscrews, Polarizing Key
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 26
Color Black
Number of Rows 2
Additional Feature POLARIZED
Fastening Type Screw Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 26
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.417 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.437 inch
Rated Current (Signal) 3A
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Durability 400 Cycles
Contact Termination Crimp
Contact Design PREASSEM CONN
Compliance
RoHS Status ROHS3 Compliant
