566-003-000-710
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Automotive Connectors 3P 2A MALE HSNG BLK 1-1.25MM 2MM PITCH
PDF
/
Inventory: 9833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Contact Termination Crimp
Note Contacts Not Included
Current Rating 2A
Pitch 0.079 2.00mm
Contact Type Male Pin
Fastening Type Latch Lock
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 3
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Waterproof (Mated, IP67)
Series 566
Published 2010
Packaging Bulk
Physical
Housing Material PBT
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 17 Weeks
