2CH-C-07
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Rectangular Connector Housing
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.1056
≥1 USD $0.1056
≥10 USD $0.08272
≥100 USD $0.068288
≥500 USD $0.063184
≥1000 USD $0.061072
≥3000 USD $0.052659
Inventory: 3683
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material BRASS
Mounting Type Free Hanging (In-Line)
Insulation Material NYLON
Mounting Option 1 LOCKING
Technical
Packaging Bulk
Series 2CH
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 7
Color White
Number of Rows 1
Fastening Type Friction Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON CU
Contact Type Female Socket
Pitch 0.079 2.00mm
Total Number of Contacts 7
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.553 inch
Operating Temperature (Max) 85°C
Operating Temperature (Min) -25°C
Rated Current (Signal) 1A
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 800VAC V
Contact Termination Crimp
Compliance
RoHS Status ROHS3 Compliant
