25CH-E-05
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
25CH RoHS Compliant COMMERCIAL UL Receptacle Connector Housing 20mOhm -40C 3A 0.682inch
PDF
/
Inventory: 7648
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material BRASS
Mounting Type Free Hanging (In-Line)
Insulation Material NYLON
Mounting Option 1 LOCKING
Technical
Packaging Bulk
Series 25CH
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 5
Color Natural
Number of Rows 1
Fastening Type Friction Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON CU
Contact Type Female Socket
Pitch 0.098 2.50mm
Total Number of Contacts 5
Reach Compliance Code compliant
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.682 inch
Operating Temperature (Min) -40°C
Rated Current (Signal) 3A
Contact Resistance 20mOhm
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Contact Termination Crimp
Compliance
RoHS Status RoHS Compliant
