1CH-A-09
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
ROHS COMPLIANT Rectangular Connector Housing
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.2728
≥1 USD $0.2728
≥10 USD $0.2332
≥100 USD $0.205568
≥500 USD $0.189024
≥1000 USD $0.181632
≥3000 USD $0.163082
Inventory: 1954
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Contact Design PREASSEM CONN
Contact Termination Crimp
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Note Contacts Not Included
Insulation Resistance 500000000Ohm
Contact Resistance 20mOhm
Rated Current (Signal) 1A
Operating Temperature (Min) -25°C
Operating Temperature (Max) 85°C
Body Length or Diameter 0.472 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Total Number of Contacts 9
Pitch 0.039 1.00mm
Contact Type Female Socket
Contact Finish - Mating SN ON CU
Subcategory Headers and Edge Type Connectors
Fastening Type Friction Lock
Additional Feature ROHS COMPLIANT
Number of Rows 1
Color White
Number of Positions 9
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1CH
Packaging Bulk
Physical
Mounting Option 1 LOCKING
Insulation Material NYLON
Mounting Type Free Hanging (In-Line)
Contact Material BRASS
Supply Chain
Factory Lead Time 9 Weeks
