1CH-A-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RCPT HSG 6POS 1.00MM
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.1672
≥100 USD $0.148192
≥500 USD $0.138336
≥1000 USD $0.12848
≥3000 USD $0.113661
Inventory: 2289
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material BRASS
Mounting Type Free Hanging (In-Line)
Insulation Material NYLON
Mounting Option 1 LOCKING
Technical
Packaging Bulk
Series 1CH
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 6
Color White
Number of Rows 1
Additional Feature ROHS COMPLIANT
Fastening Type Friction Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON CU
Contact Type Female Socket
Pitch 0.039 1.00mm
Total Number of Contacts 6
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.354 inch
Operating Temperature (Max) 85°C
Operating Temperature (Min) -25°C
Rated Current (Signal) 1A
Contact Resistance 20mOhm
Insulation Resistance 500000000Ohm
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 500VAC V
Contact Termination Crimp
Contact Design PREASSEM CONN
Compliance
RoHS Status ROHS3 Compliant
