125CH-A-09
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
125CH ROHS3Compliant COMMERCIAL UL CSA Receptacle Connector Housing 85C 1A 800VAC V 0.049 1.25mm
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.16192
≥100 USD $0.143968
≥500 USD $0.134464
≥1000 USD $0.124784
≥3000 USD $0.110387
Inventory: 1099
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 9
Color White
Number of Rows 1
Additional Feature ROHS COMPLIANT
Fastening Type Friction Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON CU
Contact Type Female Socket
Pitch 0.049 1.25mm
Total Number of Contacts 9
Reference Standard UL, CSA
Reliability COMMERCIAL
Operating Temperature (Max) 85°C
Operating Temperature (Min) -25°C
Rated Current (Signal) 1A
Insulation Resistance 500000000Ohm
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 800VAC V
Contact Termination Crimp
Contact Design PREASSEM CONN
Part Status Active
Series 125CH
Packaging Bulk
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Option 1 LOCKING
Insulation Material NYLON
Mounting Type Free Hanging (In-Line)
Contact Material BRASS
Supply Chain
Factory Lead Time 9 Weeks
