473-10-270-00-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
473 ROHS3Compliant COMMERCIAL UL Connector Header Strip 100Cycles 10mOhm -55C 3A
PDF
/
Inventory: 1725
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material BRASS
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Bulk
Published 2012
Series 473
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Connector Type Header Strip
Number of Positions 70
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Type Turret
Pitch 0.100 2.54mm
Total Number of Contacts 70
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
Operating Temperature (Min) -55°C
Rated Current (Signal) 3A
Contact Resistance 10mOhm
Insulation Resistance 10000000000Ohm
Row Spacing 0.100 (2.54mm)
Dielectric Withstanding Voltage 1400VAC V
Durability 100 Cycles
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Plating Thickness 10μin
Compliance
RoHS Status ROHS3 Compliant
