470-10-208-00-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
Rectangular Connector Header
PDF
/
Buying Options
Total Price: USD $1.97
Unit Price: USD $1.9666
≥1 USD $1.9666
≥10 USD $1.855284
≥100 USD $1.750263
≥500 USD $1.651198
≥1000 USD $1.557734
Inventory: 1108
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 10μin
Contact Finish Thickness 10.0μin 0.25μm
Technical
Durability 100 Cycles
Dielectric Withstanding Voltage 1400VAC V
Row Spacing 0.100 (2.54mm)
Insulation Resistance 10000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 3A
Operating Temperature (Min) -55°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 8
Pitch 0.100 2.54mm
Contact Type Turret
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Black
Number of Positions 8
Connector Type Header Strip
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 470
Published 2012
Packaging Bulk
Physical
Mounting Type Through Hole
Contact Material BRASS
Supply Chain
Factory Lead Time 10 Weeks
