460-80-216-00-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
Specialty Pin Rectangular Connector
PDF
/
Inventory: 6233
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Durability 100 Cycles
Dielectric Withstanding Voltage 1400VAC V
Polarization Key POLARIZED HOUSING
Row Spacing 0.100 (2.54mm)
Insulation Resistance 10000000000Ohm
Contact Resistance 10mOhm
Rated Current (Signal) 3A
Body Depth 0.11 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
PCB Contact Pattern RECTANGULAR
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 16
Pitch 0.100 2.54mm
Contact Type Slotted
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Color Black
Number of Positions 16
Connector Type Header Strip
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 460
Published 2012
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYESTER
Mounting Type Through Hole
Mount Through Hole
Contact Material BRASS
Supply Chain
Factory Lead Time 10 Weeks
