180-80-650-00-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
180 ROHS3Compliant COMMERCIAL UL Connector DIP, DIL - Header 100Cycles -55C 1A 1400VAC V
PDF
/
Inventory: 7577
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Bulk
Published 2012
Series 180
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type DIP, DIL - Header
Number of Positions 50
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Contact Type Solder Cup
Pitch 0.100 2.54mm
Total Number of Contacts 50
Number of Conductors ONE
Reference Standard UL
Contact Finish Tin
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Body Breadth 0.398 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Body Depth 0.11 inch
Rated Current (Signal) 1A
Insulation Resistance 10000000000Ohm
Row Spacing 0.600 (15.24mm)
Dielectric Withstanding Voltage 1400VAC V
Durability 100 Cycles
Compliance
RoHS Status ROHS3 Compliant
