170-10-324-00-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
Rectangular Connector Header
PDF
/
Inventory: 1511
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Insulation Material Polychlorinated
Technical
Packaging Bulk
Published 2012
Series 170
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type DIP, DIL - Header
Number of Positions 24
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 150V
Contact Type Turret
Pitch 0.100 2.54mm
Total Number of Contacts 24
Orientation Straight
Depth 10.1mm
Current Rating 1A
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Voltage - Rated AC 100V
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Body Breadth 0.398 inch
Rated Current (Signal) 1A
Insulation Resistance 10GOhm
Row Spacing 0.300 (7.62mm)
Dielectric Withstanding Voltage 1400VAC V
Durability 100 Cycles
Dimensions
Length 30.4mm
Contact Finish Thickness 10.0μin 0.25μm
Plating Thickness 10μin
Compliance
RoHS Status ROHS3 Compliant
