182-10-422-00-001000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
Conn DIP Adapter HDR 22 POS 2.54mm Wire Wrap ST Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $61.29
Unit Price: USD $61.292737
≥1 USD $61.292737
≥198 USD $24.456701
≥504 USD $23.640077
≥1008 USD $23.235704
Inventory: 1183
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Insulation Material Polychlorinated
Housing Material Plastic
Technical
Packaging Bulk
Published 2012
Series 182
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
ECCN Code EAR99
Connector Type DIP, DIL - Header
Number of Positions 22
Color Black
Number of Rows 2
HTS Code 8536.90.40.00
Voltage - Rated DC 150V
Contact Type Solder Cup
Pitch 0.100 2.54mm
Orientation Straight
Depth 12.7mm
Contact Finish Gold
Voltage - Rated AC 100V
Number of Contacts 22
Insulation Resistance 10GOhm
Row Spacing 0.400 (10.16mm)
Device Socket Type IC SOCKET
Dimensions
Length 27.8mm
Width 12.7mm
Contact Finish Thickness 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
