162-40-656-00-180000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
CONN HEADER 56POS DIP TIN PCB
PDF
/
Buying Options
Total Price: USD $20.5
Unit Price: USD $20.504
≥1 USD $20.504
≥10 USD $17.95816
≥100 USD $16.073376
≥500 USD $14.743203
Inventory: 8813
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 200.0μin 5.08μm
Length 50.08mm
Technical
Device Socket Type IC SOCKET
Row Spacing 0.600 (15.24mm)
Insulation Resistance 10GOhm
Number of Contacts 56
Voltage - Rated AC 100V
Contact Finish Tin
Depth 17.52mm
Orientation Straight
Pitch 0.070 1.78mm
Contact Type Post
Voltage - Rated DC 150V
HTS Code 8536.90.40.00
Number of Rows 2
Color Black
Number of Positions 56
Connector Type DIP, DIL - Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 162
Published 2009
Packaging Tube
Physical
Housing Material POLYETHYLENE
Insulation Material Polychlorinated
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 3 Weeks
