151-10-428-00-004000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
151 ROHS3Compliant 2000 Straight Connector DIP, DIL - Header UL94V-0 125C 100V 12.7mm
PDF
/
Inventory: 7725
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Width 12.7mm
Length 35.56mm
Technical
Device Socket Type IC SOCKET
Row Spacing 0.400 (10.16mm)
Insulation Resistance 10GOhm
Number of Contacts 28
Voltage - Rated AC 100V
Contact Finish Gold
Depth 12.7mm
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Post, Extended
Voltage - Rated DC 150V
HTS Code 8536.90.40.00
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 28
Connector Type DIP, DIL - Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 151
Published 2000
Packaging Tube
Physical
Housing Material Plastic
Insulation Material Polychlorinated
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 3 Weeks
