D6240-01

Harwin Inc.
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description HARWIN D6240-01IC & Component Socket, DIP, 40 Contacts, 2.54 mm, 15.24 mm, Tin Plated Contacts
PDF
/
Inventory: 3509
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness 137.8μin 3.50μm

Technical

Device Socket Type IC SOCKET
Row Spacing 0.600 (15.24mm)
Insulation Resistance 100000000Ohm
Body Depth 0.116 inch
Operating Temperature (Min) -55°C
Body Breadth 0.7 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 40
Lead Pitch 15.24mm
Voltage - Rated AC 100V
Contact Finish Tin
Current Rating 1A
Reach Compliance Code not_compliant
Pitch 0.100 2.54mm
Contact Type Slotted
Additional Feature ROHS COMPLIANT
Gender Male
Number of Rows 2
Color Black
Number of Positions 40
Connector Type DIP, DIL - Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2005
Packaging Tube

Physical

Housing Material POLYESTER
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass, Tin
