D6222-46
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
IC & Component Sockets 22 WAY IC HDR ASSY VERT SLOTTED DR
PDF
/
Inventory: 3434
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material BRASS
Mounting Type Through Hole
Housing Material GLASS FILLED POLYESTER
Technical
Packaging Tube
Published 2014
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type DIP, DIL - Header
Number of Positions 22
Color Black
Number of Rows 2
Additional Feature ROHS COMPLIANT
HTS Code 8536.69.40.40
Contact Type Slotted
Pitch 0.100 2.54mm
Reach Compliance Code not_compliant
Current Rating 1.5A
Contact Finish Tin
Body Length or Diameter 1.1 inch
Number of Contacts 22
PCB Contact Pattern RECTANGULAR
Body Breadth 0.5 inch
Operating Temperature (Min) -55°C
Body Depth 0.116 inch
Insulation Resistance 100000000Ohm
Row Spacing 0.400 (10.16mm)
Device Socket Type IC SOCKET
Dimensions
Contact Finish Thickness 137.8μin 3.50μm
Compliance
RoHS Status ROHS3 Compliant
