22-0600-11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
0600 ROHS3Compliant COMMERCIAL UL Connector DIP, DIL - Header 2A 2.2inch
PDF
/
Inventory: 9144
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material BRASS
Mount Through Hole
Mounting Type Through Hole
Insulation Material GLASS FILLED NYLON
Technical
Packaging Bulk
Published 2006
Series 0600
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type DIP, DIL - Header
Number of Positions 22
Color Black
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Forked
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 22
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 2.2 inch
Number Of PCB Rows 1
Lead Pitch 2.54mm
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
UL Flammability Code 94V-0
Rated Current (Signal) 2A
Body/Shell Style RECEPTACLE
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
