20-3625-11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Specialty Pin
Description
IC & Component Sockets DIP HEADERS 20 PINS SCREW MACHINE CONT
PDF
/
Inventory: 4967
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Technical
Row Spacing 0.300 (7.62mm)
UL Flammability Code 94V-0
Contact Gender MALE
Lead Pitch 2.54mm
Contact Finish Gold
Total Number of Contacts 20
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.51
Number of Rows 2
Color Black
Number of Positions 20
Connector Type DIP, DIL - Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 625
Published 2013
Packaging Bulk
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Material BRASS
Supply Chain
Factory Lead Time 5 Weeks
