D369-B99-NS4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Receptacle
PDF
/
Inventory: 9490
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material NOT SPECIFIED
Contact Plating Gold
Mount Panel
Housing Material Composite
PCB Mounting Orientation Horizontal
Technical
Termination Solder
Connector Type Receptacle, Socket
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Color Black
Number of Rows 3
Contact Finish - Mating NOT SPECIFIED
Pitch 2.54mm
Shielding Unshielded
Current Rating 5A
Row Spacing - Mating 2.54 mm
Number of Contacts 9
Operating Supply Voltage 1.5kV
Sealable Yes
Circuit Application Signal
Mating Retention With
Contact Rating (Current) 5A
Dimensions
PCB Thickness 1.6002mm
Panel Thickness 1.6002mm
Compliance
RoHS Status Non-RoHS Compliant
